	Model/Name	Characteristics	Download
	PZTO20 Rotary Torque Transducer	Desighed for wide measurement scale from 5Nm to 300,000Nm capacity; Maximum rotation speed of 450rpm; 0.5%FS measuring accuracy; speed measurement available on request
	PZTO21 Low Capacity Rotary Torque Transducer	Designed for low torque measurement from 0.005Nm to 2Nm capacity;Maximum rotation speed of 3000rpm; 0.5%fs measuring accuracy; speed measurement available on request
	PZTO30 Low Capacity Rotary Torque Transducer with Integrated Amplifier	Designed for low torque measurements; 0.1Nm, …, 5Nm capacity;Maximum rotation speed of 3000rpm; 0.5%fs measuring accuracy;amplified output & speed measurement available on request
	PZTO31 Rotary Torque Transducer & Transmitter	Desighed for wide measurement scale from 5Nm to 100,000Nm capacity; Maximum rotation speed of 15,000rpm; 0.5%FS, 0.3%FS and 0.1%FS measuring accuracies for option; amplified output signal & speed measurement available on request
